Shenzhen Kairing Technology Co.,Ltd
Fábrica Profesional de Módulos LCD
Shenzhen Kairing Technology Co.,Ltd
Fábrica Profesional de Módulos LCD
 |
| Lugar de origen: | Porcelana |
| Nombre de la marca: | Kairing |
| Certificación: | RoSH & REACH |
| Número de modelo: | KYT0280-A10 |
| Cantidad de orden mínima: | 1 |
|---|---|
| Precio: | USD / HKD or others |
| Detalles de empaquetado: | Paquete estándar |
| Tiempo de entrega: | 10 días |
| Condiciones de pago: | T/T |
| Capacidad de la fuente: | 200k / mes |
KYT0280-A10
2.8Inch TFT,Deatailed Specification
| Screen Size | 2.8inch |
| Resolution | 240 x3 RGB x320 |
| Module Size | 66.0(W) x 50.0(H)x 3.8(D) mm |
| Active Area | 57.6(H)x43.0(V) |
| Interface | 36Pins, RGB |
| Brightness | 150cd |
| Viewing Angle | 12:00 |
| Display Type | Normally White,Transmissive |
| Driver element | ILI9341 |
| Surface treatment | Anti-Glare |
| Touch Panel | With RTP or other |
1.44inch TFT Module 23pins with resolution 128*128
2.8inch TFT Module 36pins RGB interface with resolution 240*320
3.2inch TFT Module RGB interface with resistance touch panel
KMB5104 COB1602 Module Dots 16 Charactors * 2 lines with Red Color
KMB5336 COB LCD Module FSTN Positive Transflective Super-Wide Temperature of 240*128 Dots
KMB5344 COB128160 Module FSTN Positive Reflective Wide Temperature Industrial Equipment
KDF5214 FSTN Glass Panel with White Backlight STN Negative Transmissive Blue Mode Wide Temperature
