| Lugar de origen: | Porcelana |
| Nombre de la marca: | Kairing |
| Certificación: | RoHs&Reach |
| Número de modelo: | KYT0450-A04 |
| Cantidad de orden mínima: | 1 |
|---|---|
| Precio: | USD, HKD or others |
| Detalles de empaquetado: | Paquete estándar |
| Tiempo de entrega: | 10 días |
| Capacidad de la fuente: | 150K/mes |
KYT0450-A04 4.5TFT Description
| Screen Size | 4.5inch |
| Resolution | 480x3 RGB x854 |
| Module Size | 60.00(W) x 109.00(H)x 2.00(D) mm |
| Active Area | 55.44(W)*98.64(H) |
| Interface | RGB, 40PINs |
| Brightness | 300cd |
| Viewing Angle | 12:00 |
| Display Type | Normally White,Transmissive |
| Color Arrangment | RGB-stripe |
| Surface treatment | Anti-Glare |
| Touch Panel | RTP |
