| Lugar de origen: | Porcelana |
| Nombre de la marca: | Kairing |
| Certificación: | RoHS & REACH |
| Número de modelo: | KYT0700-A27 |
| Cantidad de orden mínima: | 1 |
|---|---|
| Precio: | USD / HKD or others |
| Detalles de empaquetado: | Paquete estándar |
| Tiempo de entrega: | 15 días |
| Condiciones de pago: | T/T |
| Capacidad de la fuente: | 50k/mes |
KYT0700-A27
Deatailed Specification
| Screen Size | 7.0inch |
| Resolution | 800 x3 RGB x480, 65K |
| Module Size | 190.4(PCB,L) x 105.4(PCB,W)x 17.4/15.9(H) mm |
| Active Area | 154.08(H)x85.92(V) |
| Interface | 10PINs Serial Communication for PCB Board |
| Brightness | 200cd, Adjusting as 64level |
| Serial Baudrate | 115200bps, Adjusting in 1200~1000000bps |
| Serial Mode | 8N1 UART,3.3V,CMOS |
| User Connection | 10PIN-1.0mm FCC,or 8PIN-2.0mm |
| Flash | 128MB |
| Total Weight |
310g |
